Speed display signs
ViaLED Base Solar
80 W solar panel: install it with no connection at all.
Price€2,470 excl. VAT
ViaLED Base Street Lighting – Speed display sign for lamp posts
Designed for street lights that are only powered at night: the 20 Ah internal battery charges overnight and takes over throughout the day.
- Power supplyStreet lighting (night) + internal battery (day)
- Battery12 V DC — 20 Ah
- Digits3 digits — 32 cm high
Product added to cart
Public body? Order with a quote and purchase order: deferred payment, invoice via Chorus Pro (France).
- Dispatched within 5 to 7 working days, tracked express transport
- Secure payment by card, SEPA, Apple Pay or bank transfer
- Pre-sales advice: +33 4 58 00 15 74
About the ViaLED Base Street Lighting
Most street lights are only live at night. The ViaLED Base Street Lighting makes the most of this: it runs on the mains at night while charging its high-capacity internal battery (12 V – 20 Ah), which then powers it throughout the day.
Display and behaviour
The 32 cm digits are readable from 200 m. Speed is shown continuously as long as it is respected, then flashes above the threshold chosen at installation. The SAFETY function blanks the display above the limit + 40 km/h.
Options
- Two-colour display red / green.
- Statistics pack: data collected on a USB key, CSV files compatible with Excel.
Technical specifications — ViaLED Base Street Lighting
| Power supply | Street lighting (night) + internal battery (day) |
|---|---|
| Battery | 12 V DC — 20 Ah |
| Digits | 3 digits — 32 cm high |
| LEDs | Red (red / green option) |
| Display range | 1 – 199 km/h |
| Accuracy | ± 1 km/h |
| Radar | 24,125 GHz — 5 mW (K) |
| Measuring distance | 0 – 100 m |
| Visibility | 200 m |
| Dimensions | 750 × 650 × 100 mm |
| Weight | 20 kg |
| Package | 760 × 660 × 160 mm |
| Housing | Black-painted aluminium |
| Data | USB key, CSV files (Excel) — statistics pack optional |
| Operating temperature | −20 °C / +50 °C |
| SAFETY function | Display blanked above the limit + 40 km/h |
| Ref. | VB_PUBLIC |
